Further information about the used Die sinking EDM machine OPS INGERSOLL Gantry 1200 - HSJ / 64 bit Performance
The GANTRY 1200 HSJ Performance without EROWA RAM clamping system (UPC pallet additionally mounted under the Z-axis) has the axis travel (X / Y / Z) 1000 x 1500 x 650 mm.
The GANTRY series is the epitome of flexible and economical edm solutions in tool and mould making. the good accessibility of the machine ensures fast and safe loading and set-up of the workpieces as well as monitoring of the machining process.T he work tank is completely lowered into the machine bed during filling. The maximum liquid filling height is designed to be large enough to ensure sufficient coverage even with tall workpieces. Hhe HSJ function High speed jump accelerates the z-axis to 10 mmin at 1.2 g during the lifting process of the electrode. The idle time between the individual eroding steps is shortened and at the same time optimum flushing is ensured, especially for deep slotting operations. This reduces the machining time by up to 50 percent.
