Ingersoll OPS INGERSOLL GANTRY EAGLE 500 / EAGLE 5000

The used Die sinking EDM machine OPS INGERSOLL GANTRY EAGLE 500 / EAGLE 5000 of Ingersoll (OPS Ingersoll) is currently not available. We will gladly obtain this machine for you in the near future. Get in contact
This machine is currently unavailable.
Manufacturer
Ingersoll (OPS Ingersoll)
Die sinking EDM machine
OPS INGERSOLL GANTRY EAGLE 500 / EAGLE 5000
Year Of Construction
2010
Control
EAGLE PC-NC-Dialog 2 x 32
High Speed Jump max. 18 m/min
MultiProg Powertec Technology programming for PC/NC
Powertec Easy Burn Fast programming controlunit
Generator Power
60 Ampere, EAGLE Powertec
Axis travel (X, Y, Z)
525 x 400 x 450 mm
Electrodechanger
20-times carouselchanger
Worktank (W x D x H)
770 x 670 x 440 mm
Worktable (W x D)
750 x 650 mm
Load capacity
1.000 kg
Accessories
CO2-Fire extinguisher system
Integr. Filterset Cartridge
Status
overhauled
Price
on request
Handling system
MultiChange performance IMC 5
- Multi Change basic device
- Electrode gripper ITS / Macro / H5000
- Elektrodes magazine - EROWA ITS-
with up to 154-times electrodes
- RCS-Standard gripper
- 8 Workpiece pallets
Table clamping system
EROWA UPC P chuck
ER-016841
Get in contact

Further information about the used Die sinking EDM machine OPS INGERSOLL GANTRY EAGLE 500 / EAGLE 5000

The successful GANTRY design is the basis for maximum dynamics and demanding requirements with the EAGLE POWER TEC technology. THE GANTRY EAGLE 500 fulfils stringent requirements for precision and achieves extremely good surface qualities despite complex geometries. The EAGLE POWERTEC generator adapts its discharges to the constantly changing gap conditions. High removal rates are achieved even in the case of undersized dimensions, with higher accuracy of reproduction. Reduction of costs by saving time and electrodes. The lifting speeds of 18m/min and also the optimal flushing is essential for excellent electric-dicharge machining results, even under the most difficult conditions.
